Adapters

1QT9-SP90° ELBOW METRIC MAEL 74°CONE/BSPT MALE

PART NO.	THREAD		TUBE O.D.	DIMENSIONS
PART NO.	E	F	D	A	B	S1	S2
1QT9-14-04SP	M14X1.5	R1/4"X19	8	30.2	25.5	14	17
1QT9-16-04SP	M16X1.5	R1/4"X19	10	32	26.5	16	19
1QT9-18-06SP	M18X1.5	R3/8"X19	12	34	29	19	22
1QT9-18-08SP	M18X1.5	R1/2"X14	12	36	36	22	22
1QT9-22-08SP	M22X1.5	R1/2"X14	14	37.5	36	22	27
1QT9-27-08SP	M27X1.5	R1/2"X14	18	41.5	39.5	27	32
1QT9-27-12SP	M27X1.5	R3/4"X14	18	41.5	44	27	32
1QT9-30-12SP	M30X1.5	R3/4"X14	20	45.8	45.5	30	36
1QT9-33-12SP	M33X2	R3/4"X14	22	49.5	47.5	33	38
1QT9-36-16SP	M36X2	R1"X11	25	51.5	52	36	41
1QT9-39-16SP	M39X2	R1"X11	28	55.5	55.2	41	46
1QT9-45-20SP	M45X2	R1.1/4"X11	34	62.5	61	48	55
Note:In case if you are interested to order the adapter in complete set with sleeve and nut,it is necessary to insert suffix"RN"after our part NO.,for example 1QT9-22-08SPN,The sleeve NO.is NB500-Q and the nut NO.is NB200-Q
