Adapters
4B-WDBSP MALE CAPTIVE SEAL PLUG
4B-WD BSP MALE CAPTIVE SEAL PLUG
| PART NO. | THREAD | CAPTIVE | DIMENSIONS | ||
|---|---|---|---|---|---|
| E | E | A | L | S1 | |
| 4B-02WD | G1/8"X28 | WD-B02 | 8 | 15.5 | 14 |
| 4B-04WD | G1/4"X19 | WD-B04 | 12 | 19.6 | 19 |
| 4B-06WD | G3/8"X19 | WD-B06 | 12 | 22.5 | 22 |
| 4B-08WD | G1/2"X14 | WD-B08 | 14 | 25 | 27 |
| 4B-12WD | G3/4"X14 | WD-B12 | 16 | 29 | 32 |
| 4B-16WD | G1"X11 | WD-B16 | 18 | 35 | 41 |
| 4B-20WD | G1.1/4"X11 | WD-B20 | 20 | 37 | 50 |
| 4B-24WD | G1.1/2"X11 | WD-B24 | 22 | 40 | 55 |
